Xenarc offers Rugged Monitor and Touchscreen Solutions - 7", 8", 9", 10", 12", 15", 18", 24"
Find the Rugged Display Monitor solution that is suitable for your application or system integration project. Most of our Rugged Monitors uses Automotive Grade components, which exceeds Industrial Grade.
This means they have wider operating temperature range and more durable than regular Industrial Monitors.
Xenarc Technologies also provides OEM / ODM Rugged Monitor Customization services if you don't find a suitable rugged monitor that matches your requirements.
For full specifications of this product model please visit the XENARC site clicking HERE
PRODUCT DETAILS
The Xenarc 1569 series of 15.9” touchscreen displays is perhaps the most versatile and all-encompassing product in Xenarc Technologies’ line up of products. This 16:9 1000 NIT High Bright Touchscreen is IP67 and IK08 rated and includes an optically bonded capacitive touchscreen, making it ideal for any harsh industrial environment. The 15.6 inch touch panel is optically bonded to the LCD panel, eliminating the air gap between the two, increasing clarity, contrast, and durability. Further, because the 15.6" touchscreen display unit is water tight and air tight, ambient humidity will not affect the clarity or viewability because of the advanced optical bonding. The 1569GNH 15 inch touchscreen monitor outperforms all automotive grade panels with a wider operating temperature range of -30C ~ 85C (-22F ~ 185F) and uses an IPS panel (In-Plane-Switching), which provides a wider viewing angle, consistent and accurate colors from all viewing angles, clearer images, and stable response times. A high contrast ratio of 800:1 provides crisper images and vivid colors, even in direct sunlight.
The versatility of the 1569 series extends beyond its usability in many different environments. The 1569GNH can video interface through our proprietary 26 pin cable (HDMI, VGA, AV Inputs) as well as HDMI direct into the monitor. The 15.16 touchscreen display monitor comes with an HDMI output that allows you to chain up a few 1569 series 15.6" touchscreen monitors or output to other HDMI monitors. With the included waterproof cables, the 1569GNH is IP67 on all sides and angles. The casing of the 1569GNH is designed to be used as a stand-alone monitor as well as a panel mount monitor. 75mm x 75mm VESA standard mounting holes on the back further provide users with numerous mounting options. The IK08 rating makes the 1569GNH vandal resistant and shock resistant.
The 1569GNH was designed for those looking for a true rugged, bright, compact display, usable in just about any environment or application.
Why do our 15.6" Touchscreen Display products outlast others in extreme conditions? Why do our products have a wider temperature range and a wider voltage input range? It is because our mission is to offer engineers, automators and system integrators the best products for any situation. By utilizing high grade components, this display is perfect for industrial, in-car computing applications or any other applications where a small, durable, environmentally rugged display is required, including but not limited to:
Broadcast & Production - Broadcast Stations, Mobile Production Vehicles, Field Rugged Deployment for your mobile workforce, Studio Video Production
Transportation - Marine, Air, Heavy Vehicles, Mining, Weigh Stations, Fleet Management, Telematics, In-Car Computing, Public Transit, Cargo
System Integration - Machinery Controls, Factory Automation, Environmental Monitoring, Home Automation, Military, Smart Home
Point of Sale - Hospitality, Digital Signage, Self-Service Kiosks, Outdoor Kiosks and Signage, Casino
Data Monitoring - Cloud, IoT, Medical, Logistics, Inventory Management, Oil & Gas/Utilities, Law Enforcement, Broadcasting, Veterinary, First Person View
Sunlight Readable – Ready for all environments
Waterproof/Dustproof– Built to Stringent IP67 Standards
Bonded Glass – Optically Enhanced for clarity and viewability
Multiple Inputs – HDMI, SDI, DVI, VGA, and AV Inputs
Automatic Dimming – Built in Ambient Light Sensor
Superior Image – Scalable resolution up to 1080P
Extended Temperature Range
PRODUCT FEATURES
IP67 / NEMA6P Rated Water and Dust Resistance (Whole Unit)
Super Wide Operating Temperature range of -22°F ~ 185°F (-30°C ~ 85°C)
1,000NIT Sunlight Readable with Long Life LED Backlight
Wide Viewing Angle IPS (In-Plane Switching) LCD Panel
Automatic Backlight Adjustment through Built-in Ambient Light Sensor
Projected Capacitive Multi-Touch Touchscreen (USB)
Optical Bonding, Anti-Reflective and Anti-Fingerprint Coating
Plug-N-Play with Windows 7 and up and Android devices (Downloadable drivers for other OS)
Multi-Monitor Touchscreen Support
HDMI Input x 2 (HDCP), VGA Input (15 pin D-SUB) x 1 & Video Input x 2
HDMI Output x 1, Analog Audio Output x 1
Audio Input x 4 / Built-In Waterproof Speaker
1920x1080 Native Resolution, 16x9 Aspect Ratio
Chip Monolithic Ceramic Capacitors for Improved Durability
High Performance Image and Video Signal Processor
AISS - Advanced Image-Scaling and Shaping
Last Input and Power Setting Memory
IR Remote Control
Auto Power-On upon signal detection
Vertical Image Flip
Function to Disable Front Button(s) and On Screen Text
AV2 Auto Switching for Backup Camera
VESA 75mm Mounting Holes
Panel Mountable with included hardware
26-Pin Heavy-Duty Connector with Connector Locking
Ruggedized Aluminum Casing
Supports 9V DC ~ 28V DC
"E" Mark Certified for Automotive use
FCC, CE, E13 Certification
IK08 Impact Resistant
ROHS, REACH, ECE R118-03 Compliant
36 Month/3 Year Warranty
30 Day No dead Pixel Guarantee
